SnapUp Musique B200

BUTTON OPERATIONS

Button Functions

MFB (Power): Long press to Power On/Off the headset

Answer/End Call: Single press to Play/Pause your music

Reject Incoming Call: Press Power Button two times

Next track: Single press Volume+

increase volume: Long press Volume+

Previous track: Single press Volume–

Decrease volume: Long press Volume–

Remarks:

• For some BT enabled devices, you have to choose “Transfer the sound through Bluetooth®” in the “setting” of music player of the BT enabled device and select Musique B200 in the device list.
• The music will be transmitted to the headset instead of speakers. Please refer to the instructions of your BT enabled device’s User Manual for further information.
• Control the function of last song/ next song/ Pause/ Play; it needs your mobile phone to support AVRCP. Please refer to the instructions of your BT enabled device’s User Manual for further information.
• If your BT enabled device’s music player has an option to On/Off the stereo mode, then switch it ON and select Musique B200 in the device list for better sound quality. Please refer to the instructions of your BT enabled device user manual for further information.

CARE AND MAINTENANCE

Please read the following suggestions carefully. These will help you fulLfill any warranty obligations to enjoy the product for a long time.

• Keep it dry; don’t put it in the damp place so as not to affect the internal circuit of the product.
• Don’t put the product under the sunlight or in hot areas. High temperature will shorten the life of electronic device, or might destroy the battery, or distort certain plastic material.
• Don’t expose the product to cold areas. It might damage the internal circuit board.
• Don’t attempt to dismantle various components of the product. It might damage the product that would lead to warranty void.
• Do take proper care in handling the product so as to prevent it from falling off on the floor.
• Don’t use harsh chemicals or detergents to clean the product.
• Don’t scrape the surface with sharp objects. If the product doesn’t work normallv. please send it to the nearest Service Center. The staff will assist you with a solution.

Note:

• Working Time mentioned is based on user’s operations and type of music played.
• Product specifications are subject to change without notice.
• All trademarks, logos, brands & products of their respective owners.

BEFORE USING THE DEVICE

1. Volume Up / Next Track
2. Power On/Off, Play/Pause, Answer/End Call Reject Call / Voice assistance
3. Volume Down / Previous Track
4. LED Indication
5. Micro USB port for charging

A. Charging Battery of the Bluetooth® Headset:

First time charging: This Headset has a built-in- rechargeable battery. It is recommended to charge the battery fully before using it for the first time.

LOW Power: The Headset will switch OFF automatically when the battery is fully drained. At this time you would require to charge the battery of Headset.

B. Charging the Headset with Travel Charger (Optional)

STEP 1: Connect the travel charger using USB cable to the charging port of the headset.

STEP 2: Plug the travel charger in the standard AC power outlet.

Charging the Headset with USB Cable

STEP 1: Connect charging cable with charging port of the headset.
STEP 2: Insert USB charging cable into USB port of PC / Laptop.

Note:

• When the LED is ON, the headset is charging.
• When the LED turns OFF the headset is fully charged.
• It takes approximately 1 Hr. for the headset to get fully charged.

Warning:

1. The battery is recycled.
2. Do not dispose of the battery in fire, as it may cause explosion.

BASIC OPERATION

A. Switching ON / OFF the Headset

Function

Switch On the Headset

Operation

Long Press Power Button

Switch Off the Headset

Long Press Power Button

Enter into pairing mode

After the headset is switched On, it will search for the last paired device. After 7 to 8 seconds it will automatically enter into pairing mode.

Remark: Please switch Off the headset manually whenever not in use to save battery.

B. Pairing the Headset with Bluetooth® BT enabled device

You have to pair the Bluetooth headset with BT enabled device before using it for the first time. Please make sure your BT enabled device has Bluetooth function. Specific pairing procedures may vary with different BT enabled devices. Please refer to your BT enabled device’s User Manual for further information.

The steps are as follows:

a. Pairing with Bluetooth® enabled device:

1. Keep the headset and Bluetooth® enabled device within 1 m range.
2. Make sure that the headset is OFF.
3. Switch ON the headset until you see the Blue & Red LED glowing every second. It automatically gets into pairing mode.

4. Switch ON the Bluetooth® function of your BT enabled device and search for Bluetooth® device. Select Musique B200 in the Bluetooth® device list.

5. According to indication, enter password or PIN No: “0000”, and press “Yes” or “Confirm”.

6. After successful pairing, select Musique B200 in the Bluetooth® device list, and press “Connect”. After successful connection, the indicator light will flash every 5 seconds.

PAIRING INSTRUCTIONS

• Pairing with Bluetooth® enabled device:

1. Keep the headset and Bluetooth® enabled device within 1 m range.
2. Make sure that the headset is OFF.
3. Switch ON the headset until you see the Blue & RedLED glowing every second. It automatically gets intopairing mode.
4. Switch ON the Bluetooth® function of your BTenabled device and search for Bluetooth® device.Select Musique B200 in the Bluetooth® device list.
5. According to indication, enter password or PIN No:”0000″, and press “Yes” or “Confirm”.
6. After successful pairing, select Musique B200 in theBluetooth® device list, and press “Connect”.
7. After successful connection, the indicator light will flash every 5 seconds.
